Buss Bar HD 2 x 6Way 4 Stud Stepped with Cover
Buss Bar HD 2 x 6Way 4 Stud Stepped with Cover
SAW-302235
$65.50 $68.95
$3.45 off RRP of $68.95
Product Overview
Blue Sea Systems Terminal Blocks
Fully insulated independent terminal blocks to isolate circuits
Features:
- Each screw pair is one isolated circuit
- Terminal Block Jumpers allow creation of common circuits
- Closed back design insulates power from the mounting surface
BLA Code Circuits AC/DC AC/DC Terminal Length Mounting Centres
Amps A Volts V Screw mm (A) mm (B)
BS-2402 2 20 300 #6 36 29
BS-2404 4 20 300 #6 55 48
BS-2406 6 20 300 #6 74 67
BS-2408 8 20 300 #6 93 86
BS-2410 10 20 300 #6 112 105
BS-2502 2 30 600 #8 54 43
BS-2504 4 30 600 #8 83 71
BS-2506 6 30 600 #8 111 100
BS-2510 10 30 600 #8 168 157
BS-2512 12 30 600 #8 197 186
BS-2602 2 65 600 #10 64 52
BS-2604 4 65 600 #10 99 87
BS-2606 6 65 600 #10 99 122
BS-2608 8 65 600 #10 134 157
BS-2610 10 65 600 #10 203 192
Accessories:
BS-9218 Terminal Jumper For use with 20A Terminal Blocks (pack of 5)
BS-9217 Terminal Jumper For use with 30A Terminal Blocks (pack of 5)
BS-9216 Terminal Jumper For use with 65A Terminal Blocks (pack of 5)
| SKU | BLA-BS-2512 |
| Brand | Blue Sea Systems |
